Mini-ITX Form Factor Carrier Board For Qseven Module with Dual Displays and Two GbE

Ordering Guide

Larger Image(s)

Datasheet

Quote & Request

Features

Qseven carrier board accepts Portwell Qseven
modules

Intel^®Atom™ Z5XX and SCH US15W

Mini-ITX form factor for embedded applications

Dual PCI interface Gigabit Ethernet ports

One IDE channel and Two SATA150 Ports

One PCI and PCI-E x1 expansion slot via riser
card

Ordering Guide


	PQ7-C200	Mini-ITX Carrier Board for Qseven Module with Dual Displays and Two GbE
	PQ7-M100G	Qseven module based on Intel^® Atom™ Processor with DDR2 SDRAM, LVDS Display, Gigabit Ethernet, SDVO
	PQ7-M101G	Qseven module based on Intel^® Atom™ Processor with DDR2 SDRAM, LVDS Display, Gigabit Ethernet, SDVO and SATA

*Specifications are subject to change without notice.
