| CPU |
CPU & Package: Intel®
Pentium® 4 in the mPGA478 package |
| Chipset |
Intel® 875P and Intel®
6300ESB |
| FSB |
533 / 800MHz Front
side bus |
| System Memory |
Up to 2GB DDR 333/400
Dual channel SDRAM on two 184-pin DIMM sockets |
| BIOS |
Award BIOS |
| Ethernet |
-10Base-T/100Base-TX/1000Base-T
Ethernet
-IEEE 802.3U Auto-negotiation
-Dual RJ-45 connector with two LED indicators |
| Display |
-ATI M10 Graphics
controller (M11 Option)
-64MB display memory (128MB M11 Option)
-Display resolution up to 2048x1536 at 60Hz refresh
-Superior 2D, 3D and video performance |
| EIDE |
Support Four EIDE devices
with Ultra DMA 100/66/33 |
| SCSI, Expansion Interface |
N/A |
| Audio |
AC' 97 2.2 Audio |
| ISA Bus |
64mA high driving ISA
bus interface to backplane |
| Solid State Disk |
-One Type II CompactFlash
CF socket
-One secondary EIDE channel
-Bootable for no drives on primary channel |
| I/O |
-Support two SATA 150
devices
-Two serial (RS-232 x1, Selectable RS-232/422/485
x1) & One IrDA 1.0
-Four USB2.0 ports
-8 high driving GPIO (4 GPI, 4 GPO)
-One 6-pin mini DIN connector for keyboard and mouse |
| ACPI Function |
-ATX function with 4-pin
header connect to backplane
-Modem-Ring-On and Wake-On-LAN (WOL) |
| Hardware Monitoring |
System monitor (fan,
temperature, voltage) |
| Watchdog Timer |
Programmable via software
from 0.5 sec to 254.5 min. |
| Mechanical |
Dimension:
338.5 (L) x 122 (W) mm
13.33" (L) x 4.8" (W) |
| Environment |
Operating Temperature:
0 Celcius |
