Specifications

Input

Voltage

90V ~ 132V, 180V ~ 264V AC selectable

Efficiency

> 68%

Holdup Time

16.7 ms. at full load

Over Voltage Protection

+5V: 5.6V ~ 6.5V; +3.3V: 4.0V ~ 4.5V; +12V: 13.5V ~ 15.5V

Over Power/Load Protection

+5V, +3.3V, +12V, output power over 105% ~ 160%

MTBF

100,000hrs

Temperature/Humidity

Operating: 0 ~ 40°SSSC, 10 ~ 90%RH
Storage: -40 ~ 70°SSSC, 5 ~ 95%RH

Safety Approval

Dimension(WxDxH)

150x140x86 mm / 5.9"x5.5"x3.4"

DC Output

+5V

+3.3V

+12V

-5V

-12V

+5Vsb

Max. Load

30A

28A

16A

0.3A

0.8A

2A

Min. Load

0.1A

0.3A

0A

0A

0A

0A

Max. Watt

200W

200W

192W

1.5W

9.6W

10W
