Specifications

Input

Voltage

90V ~ 264V AC, full range

Efficiency

> 65%

Holdup Time

16 ms. at full load

Over Voltage Protection

5V: 5.5V ~ 7.0V; +3.3V: 3.5V ~ 4.5V; +12V: 12.7V ~ 15.6V

Over Power/Load Protection

Output power over 120% ~ 140%

MTBF

100,000hrs

Temperature/Humidity

Operating: 10 ~ 50°SSC, 20 ~ 80%RH
Storage: -40 ~ 70°SSC, 10 ~ 95%RH

Safety Approval

Dimension(WxDxH)

150x140x86 mm / 5.9"x5.5"x3.4"

DC Output

+5V

+3.3V

+12V

-5V

-12V

+5Vsb

Max. Load

35A

20A

22A

0.5A

0.8A

2A

Min. Load

5A

1A

2A

0.1A

0.1A

0.1A

Max. Watt

328W

328W

328W

2.5W

9.6W

10W
