- Four Gigabit Ethernet ports via x1 PCI-Express
provide wire-speed like performance
- Variable combination with 32-bit Gigabit
Ethernet from 2, 4 and 6 ports (by model)
- Support most up-to-date LGA 775 CPUs up
to 3.4GHz with 800MHz FSB
- Support dual channel DDR, up to 2GB
- Optional RAID 0,1 function with two 2.5"
HDD
- Optional bypass function on four PCI-Express
GbE ports
- Optional crypto solution: Cavium CN1010
to be built 32bit by project
- One rear-accessible PCI expansion slot
|
|
 |
| Part
No. |
PCI-E
GbE |
32bit
GbE |
Bypass |
EZIO |
PCI-Slot
|
| NAR-5500-410 |
4 |
N/A |
N/A |
Yes |
1 |
| NAR-5500-610 |
4 |
2 |
N/A |
Yes |
1 |
| NAR-5500B-610 |
4 |
2 |
2
Segments |
Yes |
1 |
| NAR-5500B-810 |
4 |
4 |
2
Segments |
Yes |
1 |
|
|
- Specifications are subject to change
without notice.
- Pentium 4, Pentium III, Pentium
II and Celeron are registered trademarks of Intel®
Corporation.
|
|
| |
|
